Low Pressure Polyurethane(PU) Foaming Machine
Multi-Component PU Machine
We also have a wide range of multi-component low pressure PU foaming machines, which helps customers differentiate their products and maximize their productivity by designing product processes, including ancillary equipment together.
Knowledge and Experience in Rotor Design
Based on our many years of experience, we have designed smart rotors that can efficiently mix and stir raw materials with different viscosities and mixing ratios, and can also handle high-viscosity raw materials and raw materials containing fillers.
Application
- Automotive Interior parts, Automotive exterior parts, Insulation / building material panel, furniture
Features
- Mixing head based on many years of experience enables efficient stirring and mixing of raw materials with different viscosities and mixing ratios. We can also handle high-viscosity raw materials and raw materials containing fillers.
- Temperature control device is also built into the unit and features a compact design.
- Can also propose automated lines and blending equipment that combine ancillary equipment.
Specification
| Model | Number of ingredients | Injection capacity （Kg/min） |
|---|---|---|
| A-201 | 2 | 0.5〜1 |
| A-203 | 2 | 1〜3 |
| A-210 | 2 | 5〜10 |
| A-630 | 6 | 10〜30 |
| A-250 | 3 | 20〜50 |
| A-3100 | 3 | 50〜100 |
- ※Specifications can be changed according to the application. Please contact us.
