Supercritical Fluid Extraction(SFE) equipment for extraction and cleaning
We are a manufacturer of custom-built CO2 Supercritical Fluid Extraction(SFE) equipment which is environmentally friendly and can mildly extract useful/valuable components or cleaning semiconductor efficiently, resulting in your cost down
Efficient and Non-Destructive Extraction
Our supercritical CO₂ system operates with CO₂ above its critical point, enabling a process that combines liquid-like solvency with gas-like diffusivity. This yields unique advantages not available in conventional solvent systems, including low-temperature operation, near-zero solvent residue, and reduced environmental impact.
This machine can be used for extracting useful ingredients from natural products (animals and plants), injecting functional ingredients into materials, and cleaning products.
Features
-
Since it uses carbon dioxide, it is a system that is friendly to people and the environment.
Carbon dioxide can be recovered and used repeatedly. (Replenishment is required)
- Selective extraction is possible by changing the temperature and pressure of carbon dioxide.
- Can be modified and functionalized without impairing the original characteristics of materials and products.
- Compared to the solvent extraction method, the solvent separation process is not required, and the extraction and separation is labor-saving and energy-saving.
- By adopting a unique method for the high-pressure tank lid, the lid can be opened and closed easily and quickly.
- ※Since this equipment falls under the "Type 2 manufacturing equipment" stipulated by the High Pressure Gas Safety Act, it is necessary to notify the prefecture when installing it.
Specification
| High pressure tank | Design pressure | temperature | Carbon dioxide discharge amount | Entrainer discharge amount | utility |
|---|---|---|---|---|---|
| 50L | Max 30MPa | Max 100℃ | Max 400cc/min | Max 300cc/min | 3-phase 200V/220V Air Water supply / drainage |
- ※Specifications can be changed according to the application. Please contact us.
